Home > Standard Hardware > Fasteners > Multi-station Cold heading machine

Guangzhou Innor Machinery Co.,Ltd Company  |  Products  |  News  |  Contact Us Multi-station Cold heading machine Model: dd8x 105-4 Model DD 8X 105-4 Forging Station (Nos.) 4 Max. Cut-off Dia.(mm) 8 Max. Cut-off Length (mm) 105 Static Die Ejection Length C ??.O Stroke????0 Dynamic Die Ejection Length (mm) 20 Cut-off Die Size (mm) ?35X56 Static Die Size / Main Die Size.(mm) ?60X105 Dynamic Die Size / Punch Die Size (mm) ?45X110 Static Die Center Distance / Die Pitch (mm) 87 Main Slider Stroke (mm) 150 Screw Size can be made??m???? Max. Length 75 Min. Length 16 Max.Output(Pcs./Min.) 240 Main Motor(Kw) 18 Weight (Kg) 10000 Related Products cold heading machine Guangzhou Innor Machinery Co.,Ltd Model ID 10 X 190 Forging Station (Nos.) 1 Max. Cut-off Dia.(mm) 10 Max. Cut-off Length (mm) 190 Static Die Ejection Length (mm) (K.O Stroke) 155 ... cold heading machine Guangzhou Innor Machinery Co.,Ltd Model ID 8 X 110 Forging Station (Nos.) 1 Max. Cut-off Dia.(mm) 8 Max. Cut-off Length (mm) 110 Static Die Ejection Length (mm) (K.O Stroke) 90 Dynamic ... cold heading machine Guangzhou Innor Machinery Co.,Ltd Model ID 5 X 85 Forging Station (Nos.) 1 Max. Cut-off Dia.(mm) 5 Max. Cut-off Length (mm) 85 Static Die Ejection Length (mm) (K.O Stroke)90 P.K.O ... cold heading machine Guangzhou Innor Machinery Co.,Ltd Model ID 6 X 130 Forging Station (Nos.) 1 Max. Cut-off Dia.(mm) 6 Max. Cut-off Length (mm) 130 Static Die Ejection Length (mm) (K.O Stroke) 110 ... cold heading machine Guangzhou Innor Machinery Co.,Ltd Model ID 5 X 85 Forging Station (Nos.) 1 Max. Cut-off Dia.(mm) 5 Max. Cut-off Length (mm) 85 Static Die Ejection Length (mm) (K.O Stroke) 90 Dynamic ...
